HOR22-8040 oxidation-resistant RO membrane
HOR22-8040 HOR Series is the oxidation-resistant polyamide membrane element independently developed by VONTRON. Aiming to overcome the shortcoming of low oxidation resistance commonly existing in traditional polyamide RO membrane, it utilizes unique applies specialized synthesizing process to strengthen the oxidation resistance of membrane element, allowing the disinfectants to be directly added into the on-line elements, thus achieving the complete asepsis of RO main body.
Applicable Industries: municipal water supply and wastewater, for example: tap water, electroplating wastewater, industrial water, etc. Production of sterile water, such as cosmetics water, pharmaceuticals water, etc.
| Model: | HOR22-8040 |
| Salt rejection: | 99.5% |
| Effective membrane area: | 37.2㎡ |
| Test pressure: | 15.5bar |
| Capacity: | 9000GPD |
| Membrane type: | T.F.C |
| PH range for continue working: | 2-11 |
| Brand Name: | Vontron |
| Condition: | New |
| Size: | 201*201*1016mm |
| Weight: | 13KG |
| Material: | CARTON |
| Applicable Industries: | Hotels, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Food & Beverage Shops |
Deet sheet | |
Typical Properties
| Product | Active area ft²(m²) | Permeate flow rategpd(m³/d) | Stabilized salt rejection(%) |
| HOR22-8040 | 400(37.2) | 9000(34) | 99.5 |
Element Dimensions
Replacable model for each Brand RO membrane
| DOW Filmtec | Hydranautics | Toray | Daltonen | Vontron | CSM | LG | |
| 4inch backwash RO membrane | BW30PRO-4040 | CAP2-4040 | TM710D | BW4040PRO | LP21-4040 | RE4040-BE | BW 4040 R |
| 8inch brackish RO membrane | BW30PRO-400 | CAP3-LD | TM720D-400 | BW8400PRO | LP21-8040 | RE8040-BE | BW 400 R Dura |
| 8inch brackish RO membrane Fouling Resistant | BW30FR-400 | LFC3-LD | TML20D-400 | FR8400 | FR12-8040 FR22-8040PRO | RE8040-FEN | BW 400 AFR |
| 8inch sea water RO membrane | SW30HR-380 | SWC5-LD | TM820M-400 TM820V-400 | SW8400HR SW8400HRLE | SW8040HR-400 | RE8040-SHA400 RE8040-SHF | SW 400 SR SW 400 R |
Our Certificate
Our Stock
