SW8040HR-400

Vontron Sea Water Desalination SW8040HR-400 Membrane

sea water desalination SW8040HR-400 SW series of aromatic polyamide compound membrane element developed by Vontron Membrane Technology Co., Ltd. is applicable to desalination of seawater. By optimizing the structure of membrane element, the SW series increases the permeate flow, and requires fewer elements for same permeate flow. It is characterized by low operating pressure, low investment in equipment, excellent rejection rate and reliable performance. Applicable to treatment of seawater and high-concentration brackish water, the SW series of membrane element is designed for various industrial water treatment, such as seawater desalination, high-concentration brackish water desalting, boiler water replenishment for power plant, and various fields such as recycling of wastewater, concentration and reclamation of such substances with high additional value as foodstuff, pharmaceuticals, etc.

  • Characters of SW8040HR-400 Membrane Elements:
  • High rejection rate, stable rejection rate 99.8%.
  • High deboration rate, ensure the safety of drinking water.
  • Lower energy consumption, reduce the investments and operation costs.
  • Higher cross-linking index of polyamide layer, wider pH range of cleaning
Model:SW8040HR-400
Salt rejection: 99.8%
Effective membrane area:37.2㎡
Test pressure:15.5bar
Capacity:7,500GPD
Membrane type:T.F.C
PH range for continue working:2-11
Brand Name:Vontron
Condition:New
Size:201*201*1016mm
Weight:13KG
Material:CARTON
Applicable Industries:Hotels, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Food & Beverage Shops
Deet sheetSW8040HR-400.pdf

Typical Properties

ProductActive area ft²(m²)Permeate flow rategpd(m³/d)Stabilized salt rejection(%)
SW8040HR-400400(37.2)7500(39.7)99.8

Element Dimensions​

SW8040HR-400 Element Dimensions

Our Certificate

Our Stock

Our Shipments

Contact Us, We will answer your email shortly! ​

Weight13 kg
Dimensions20.1 × 20.1 × 101.6 cm
size

8 inch sea water RO membrane
