ULP21-4040

VONTRON Ultra Low Pressure Membrane ULP21-4040

VONTRON Ultra Low Pressure Membrane ULP21-4040, ULP series of ultra low pressure aromatic polyamide RO element is developed by VONTRON for treatment of surface water and underground water. Its operation pressure is about 2/3 of low pressure membrane, and the rejection rate can reach 99.5%. Thus it can reduce the investment cost of related pumps, pipelines, containers and other equipments and the operation cost of reverse osmosis system, improve economic benefits. ULP series RO element normally suitable for treatment of surface water, underground water and municipal water with TDS is less than 2000 ppm. It is mainly applied in bottle water, drinking water, boiler replenishment water, food processing and pharmaceutical manufacturing industries and other fields.

Model:ULP21-4040
Salt rejection:99.0%
Effective membrane area:8.4㎡
Test pressure:15.5bar
Capacity:2,400GPD
Membrane type:T.F.C
PH range for continue working:2-11
Brand Name:Vontron
Condition:New
Size:100*100*1000mm
Weight:4KG
Material:CARTON
Applicable Industries:Hotels, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Food & Beverage Shops
Deet sheetULP21-4040.pdf

Typical Properties

ProductActive area ft²(m²)Permeate flow rategpd(m³/d)Stabilized salt rejection(%)
ULP21-404090(8.4)2400(9.1)99.0

Element Dimensions​

ULP21-4040 Element Dimensions

Our Certificate

Our Stock

Our Shipments

Contact Us, We will answer your email shortly! ​

Weight4 kg
Dimensions10.0 × 10.0 × 100.0 cm
size

4 inch backwash RO membrane
